You are free to use and extend them further. I have published the above files on GitHub. A Python script that pulls data from Cisco UCS and stitches it end-to-end.UTM needs a read-only account for Cisco UCS monitoring. Finally, Grafana is used to visualize data from InfluxDB.Before that, the data is stitched end-to-end between the FI uplink port and server vNIC and vHBA. The script stores the data into InfluxDB.The script is invoked by telegraf using the exec input plugin.The metrics are polled every 60 seconds (by default) by a Python script.Cisco UCS collects metrics of various components like vNIC/vHBA, FI ports, IOM ports, etc.In brief, the architecture of UTM has the following components: For example, it stitches the end-to-end view between FI uplink ports and server vNIC and vHBA to help find issues quickly. It monitors Cisco UCS servers in a much more powerful way. UTM is much more than a traffic graphing engine. Port-channel load-balance verification.Traffic balance check – Verify if the paths A and B are equally utilized.
Detect and pin-point internal congestion via PAUSE frame monitoring on FI server ports and IOM backplane ports.When the FI uplink port is over-utilized, find which vNIC/vHBA on which adaptor on which blade in which chassis is contributing most traffic to that port.Some examples are FI port statistics (uplink and server ports), IOM statistics (network and backplane ports), vNIC and vHBA statistics, etc. UTM provides traffic visibility into Cisco UCS servers. 6.2.6 Monitoring UCS using Grafana UTM use-cases
